Exosome Research

Wako MagCapture™ Kits for the isolation and extraction of exosome extracellular vesicles in preparation for further downstream processing and analysis.

MagCapture™

Exosomes are small extracellular vesicles (EVs), typically 30-150nm in diameter containing proteins, mRNA, micro RNA, DNA and lipids, which are secreted by various cells and are present in many body fluids including blood, saliva and cerebrospinal fluid (CSF). They have been shown to be involved in many processes, including of cell-to-cell communication and biomarkers for various diseases.

As such research involving exosomes and the need to effectively identify and isolate exosomes has increased considerably. To this end we provide MagCapture exosome isolations kits, manufactured by FUJIFILM Wako Pure Chemical Corporation.

MagCapture uses a novel affinity purification method using magnetic beads and phosphatidylserine (PS)-binding protein (PS affinity method) to effectively isolate exosomes to a high standard. This is ideal for sample preparation, extraction and isolation of exosomes in preparation for any number of downstream processes, including:

  • Protein analysis: Western blot, electrophoresis, flow cytometry, ELISAs etc.

  • Nucleic acid analysis: PCR, qPCR, Next Generation Sequencing (NGS) etc.

  • Particle analysis: Electron microscopy (SEM, TEM), NanoSight analysis etc.

  • Functional analysis: Administration in in vitro or in vivo studies etc

Due to the implication of exosomes in numerous processes they have increasingly become areas of research interest in many fields including, among many others:

  • Haematology

  • Coagulation

  • Cellular Biology

  • Genetics

  • Proteomics

  • Transcriptomics

  • Bioinformatics

  • Microbiology

Exosomes have become increasingly studied for their potential use in clinical environments, both as potential treatments and biomarkers for diseases.

Research Process

Process
Production Isolation/Purification Detection/Determination Analysis
Overview Cultured cells release exosomes. The amount of production varies depending on the medium. Isolated and purified from culture supernatants or body fluid samples. The purity and recovery amount differ depending on the method. Exosomes are detected and quantified using exosome surface marker protein etc. Analyse nucleic acids (miRNA and mRNA), proteins, lipids, etc. included in exosomes.
Product Culture Media

Production Supplement

Culture Plate

Purified Exosomes

Isolation Kits

Blocking Reagents

ELISA Kits

Flow Cytometry Kits

Antibodies

Nucleic Acid Analysis

PS-affinity Method

In exosome research, it is important to isolate and purify exosomes in a state close to their in vivo state with high purity and high yield. There are many methods for isolation and purification of exosomes, including ultracentrifugation and polymer precipitation, but each method has problems such as presence of many impurities, low recovery amount, and damage to recovered exosomes.

Fujifilm Wako developed a new exosome isolation and purification technique, the "PS-affinity method", using Tim4 protein, which specifically binds to phosphatidylserine (PS) on the surfaces of extracellular vesicles, including exosomes.

This novel method is featured in the MagCapture isolation kits, the Flow cytometry, and some ELISA kits.

Conventionally, ultra-centrifugation, affinity purification, and precipitation with polymer reagents are used for isolation of exosomes. However, these methods have limitations in their performance, particularly recovery efficiency, purity and ease-of-use.

Ultra-centrifugation Density Gradient Centrifugation Polymer Precipitation Antibody Affinity Method PS (phosphatidylserine) Affinity Method
Overview Precipitates exosomes by ultracentrifugation at 100,000 x G. After addition of sucrose, centrifuge and fractionate based on the sedimentation rate. Precipitate exosomes with polymers such as PEG. Exosomes are captured with immobilised antibodies, specific to antigens on the surface of exosomes. Exosomes are captured with Tim4 on magnetic beads, which binds to PS (phosphatidylserine) on the surface of exosomes.
Purity ++ +++ + +++ ++++
Yield ++ + ++

(Total protein is high)

++ +++

(Total protein is low)

Intactness Yes

(Reduced quantity)

Yes Yes No Yes

Note: comparison is based on Fujifilm Wako research. Results may vary depending on the sample, detection target and method, and the performance of each method is not guaranteed.

EV-Save Blocking Reagent

Exosomes are known to adsorb to the wall of plastic tubes, which considerably affects the exosome yield and other outcomes. In addition, as exosomes are damaged by freezing and thawing.

EV-Save™ considerably inhibits adsorption of exosomes to the tube walls and protects exosomes from the freeze-thaw damage.

ELISA Kits

Fujifilm Wako offers a line-up of ELISA kits that can be used for qualitative and quantitative analysis of extracellular vesicles. Fujifilm Wako provides high-sensitivity ELISA kits that utilize "PS-affinity method" and ELISA kits that use anti human CD9, CD63, or CD81 antibody.

See our selection table to choose a product that meets your purpose:

PS Capture™ Exosome ELISA Kits Human Antibody Capture Exosome ELISA Kits
Product Code 297-79201 298-80601 296-83701 290-83601 292-83801
Product Name PS Capture™ Exosome ELISA Kit (Anti Mouse IgG POD) PS Capture™ Exosome ELISA Kit (Streptavidin HRP) CD9-Capture Human Exosome ELISA Kit (Streptavidin HRP) CD63-Capture Human Exosome ELISA Kit (Streptavidin HRP) CD81-Capture Human Exosome ELISA Kit (Streptavidin HRP)
Capture Molecule Tim4 protein Tim4 protein Anti human CD9 antibody (Rat) Anti human CD63 antibody (Mouse) Anti human CD81 antibody (Mouse)
Detection Antibody included in kit Anti-human CD63 antibody (Mouse)

Anti-human CD63 antibody (Mouse) Anti human CD9 antibody (Rat) Anti-human CD63 antibody (Mouse) Anti human CD81 antibody (Mouse)
Enzyme Conjugation Method Secondary Antibody HRP-conjugated Anti-mouse IgG Biotin-conjugated Streptavidin Biotin-conjugated Streptavidin Biotin-conjugated Streptavidin Biotin-conjugated Streptavidin
Sample Type Purified exosomes Culture supernatant*

Purified exosomes Culture Supernatant Body fluid (incl. Serum & Plasma) Purified exosomes Culture Supernatant Body fluid (incl. Serum & Plasma) Purified exosomes Culture Supernatant Body fluid (incl. Serum & Plasma) Purified exosomes Culture Supernatant Body fluid (incl. Serum & Plasma)
Analyte (phosphatidylserine) PS-positive exosomes (phosphatidylserine) PS-positive exosomes Human CD9-positive exosomes Human CD81-positive exosomes Human CD81-positive exosomes

*As the antibody for detection reacts non-specifically with IgG, serum or plasma samples cannot be used for measurement

Exosome Research Products

Exosomes frm COLO201 cell
Purified exosomes from COLO201 cells 50µL Wako
052-09301
List Price
£961.93
Pack Size: 50µL
MagCapture Exosome Isolation&#
MagCapture Exosome Isolation Kit PS Ver2
294-84101
List Price
£491.13
Pack Size: 2 Tests
EV-Up MSC EV Production&#
EV-Up™ MSC EV Production Supplement
298-84001
List Price
£423.65
Pack Size: 100mL
PS Capture Exosome Flow&#
PS Capture™ Exosome Flow Cytometry Kit
297-79701
List Price
£765.05
Pack Size: 300Tests
CD9-Capture Human Exosome
CD9-Capture Human Exosome ELISA Kit (Streptavidin HRP)
296-83701
List Price
£2,334.74
Pack Size: 96Tests
CD81-Capture Human Exosome
CD81-Capture Human Exosome ELISA Kit (Streptavidin HRP)
292-83801
List Price
£2,334.74
Pack Size: 96Tests
MagCapture Exosome Isolation&#
MagCapture™ Exosome Isolation Kit Ver2
290-84103
List Price
£1,551.50
Pack Size: 10Tests
CD63-Capture Human Exosome
CD63-Capture Human Exosome ELISA Kit (Streptavidin HRP)
290-83601
List Price
£2,033.00
Pack Size: 96Tests
PS Capture Exosome Isolat
PS Capture™ Exosome Isolation Resin Kit
290-80301
List Price
£1,310.75
Pack Size: 1Kit
EV-Save EV Blocking Reage
EV-Save™ Extracellular Vesicle Blocking Reagent
058-09261
List Price
£379.00
Pack Size: 1mL
EV-Up EV Production Basal
EV-Up™ EV Production Basal Medium for MSC's
053-09451
List Price
£279.36
Pack Size: 95mL
EV-Save EV Blocking Reage
EV-Save™ Extracellular Vesicle Blocking Reagent for in vivo
050-09461
List Price
£400.23
Pack Size: 1mL
